产品介绍
| 机器型号 | 机针型号 | 针数 | 线数 |
针间距 mm |
包边宽 度mm |
针迹长度 mm |
抬压脚高度mm |
差动比 | 最高转速rpm |
最大 功率W |
电压V | 频率Hz |
外箱尺寸 cm |
附件箱 尺寸cm |
毛重/净重 |
| Model | Needle size | needle | thread | Gauge | Overage wideth | Stitch length | Press foot | Differential ratio | Speed | Power | Voltage | frequency | carton size | Accessory box size | G.W/N.W |
| D9-3/E | DC*27 14# | 1 | 3 | / | 4 | 4 | 5 | 0.7-2.0 | 7000 | 550 | 220 | 50-60 | 52*36*49 | 50*30*9.5 | 41/34 |
| D9-4/E | DC*27 11# | 2 | 4 | 2 | 2*4 | 4 | 5.5 | 0.7-2.0 | 7000 | 550 | 220 | 50-60 | 52*36*49 | 50*30*9.5 | 41/34 |
| D9-5/E | DC*27 14# | 2 | 5 | 3 | 3*4 | 3.8 | 5.5 | 0.7-2.0 | 6500 | 550 | 220 | 50-60 | 52*36*49 | 50*30*9.5 | 41/34 |
| D9-5H/E | DC*27 18# | 2 | 5 | 5 | 5*6 | 5 | 7 | 0.7-2.0 | 6000 | 550 | 220 | 50-60 | 52*36*49 | 50*30*9.5 | 41/34 |
